Tenda TEG3224T User Manual

24-Port Managed Gigabit Switch
4.5.2 802.1x Port Statistics
Please select the left meun as TEG3224T→Monitor→802.1x→
Port Statistics to enter the following window:
The page provides detailed IEEE 802.1X statistics for a specific
switch port. Use the port select box to select which port details to
display. The table is divided into three sections. These are:
EAPOL Counters
Supplicant frame counter statistics. There are seven receive frame
counters and three transmit frame counters.
EAPOL Counters
Direction Name IEEE Name Description
Rx Total
dot1xAuth
EapolFramesRx
The number of valid EAPOL frames
of any type that has been received
by the switch.
Rx
Response
ID
dot1xAuth
EapolRespId
FramesRx
The number of valid EAP Resp/ID
frames that have been received by
the switch.
Rx Responses
dot1xAuth
EapolResp
FramesRx
The number of valid EAPOL
response frames (other than
Resp/ID frames) that have been
126
