24-Port Managed Gigabit Switch
3.13 Access Control List (ACL)
3.13.1 ACL Introduction
With the booming increase of network scale and traffic, it becomes
more and more important to implement network security and
bandwidth distribution. Usually by packet filtering, you can prevent
the unauthorized users to access the Internet, control the traffic and
save network resources.
ACL (Access Control List) is used to specify the traffic filtering rules
to control the user’s access rights. When the port receives the
packets, the port configured rules will analyze and decide which ones
would be forwarded or filtered. Generally speaking, ACL is deployed
to control access rights by destination MAC address, source MAC
address, destination IP address, source IP address, protocol and port
number and so on.
3.13.2 ACL Configuration
3.13.2.1. ACL Configuration
Please select the left meun as TEG3224T→Configuration→
ACL→ Wizard to enter the following window:
73
