24-Port Managed Gigabit Switch
3.14.2 Mirroring Configuration
Please select the left meun as TEG3224T→Configuration→
Mirroring to enter the following window:
Configure port Mirroring on this page. To debug network problems,
selected traffic can be copied, or mirrored, to a mirror port where a
frame analyzer can be attached to analyze the frame flow. The
traffic to be copied to the mirror port is selected as follows:
All frames received on a given port (also known as ingress or
source mirroring).
All frames transmitted on a given port (also known as egress
or destination mirroring).
Port to mirror to
Frames from ports that have either source or destination
mirroring enabled are mirrored to this port. Disabled disables
mirroring.
105
