Tenda TEG3224T User Manual

24-Port Managed Gigabit Switch
3.12.4 QoS Configuration
3.12.4.1 QCL Configuration Wizard
Please select the left meun as TEG3224T→Configuration→
QoS→ Wizard to enter the following window:
This handy wizard helps you set up a QCL quickly in void of
complicate settings. The wizard consists of:
1. Set up Port Policies：
Group ports into several types according to different QCL policies.
QCL ID
Frames that hit this QCE are set to match this specific QCL.
Port Members
A row of radio buttons for each port is displayed for each QCL
ID. To include a port in a QCL member, click the radio button.
2. Set up Typical Network Application Rules
Set up the specific QCL for different typical network application
quality control.
64
