24-Port Managed Gigabit Switch
Audio and Video
Indicates the common servers that apply to the specific QCE.
The common servers are: QuickTime 4 Server, MSN
Messenger Phone, Yahoo Messenger Phone, Napster, Real
Audi
o.
Games
Indicates the common games that apply to the specific QCE.
User Definition
Indicates the user definition that applies to the specific QCE.
The user definitions are:
Ethernet Type: Specify the Ethernet Type filter for this QCE.
T
he allowed range is 0x600 to 0xFFFF.
VLAN ID: VLAN ID filter for this QCE. The allowed range is 1 to
4094.
UDP/TCP Port: Specify the TCP/UDP port filter for this QCE.
T
he allowed range is 0 to 65535.
DSCP: Specify the DSCP filter for this QCE. The allowed range
is 0 to 63.
3. Set
up ToS Precedence Mapping
Set up the traffic class mapping to the precedence part of ToS (3
bits) when receiving IPv4/IPv6 packets.
QCL ID：
Select the QCL ID to which this QCE applies.
ToS Precedence Class
Select a traffic class of Low, Normal, Medium, or High to apply
to the QCE.
65
