24-Port Managed Gigabit Switch
classified VLAN of the frame, the frame is discarded. By default,
ingress filtering is disabled (no checkmark).
Frame Type
Determine whether the port accepts all frames or only tagged
frames. This parameter affects VLAN ingress processing. If the
port only accepts tagged frames, untagged frames received on
the port are discarded. By default, the field is set to All.
Port VL
AN Mode
Configures the Port VLAN Mode. The allowed values are None
or Specific. This parameter affects VLAN ingress and egress
process
ing.
If None is selected, a VLAN tag with the classified VLAN ID is
inserte
d in frames transmitted on the port. This mode is
normally used for ports connected to VLAN aware switches.
If Specific (the default value) is selected, a Port VLAN ID can
be co
nfigured (see below). Untagged frames received on the
port are classified to the Port VLAN ID. If VLAN awareness is
disabled, all frames received on the port are classified to the
Port VLAN ID. If the classified VLAN ID of a frame transmitted
on the port is different from the Port VLAN ID, a VLAN tag with
the classified VLAN ID is inserted in the frame.
Port VLAN ID
Configures the VLAN identifier for the port. The allowed values
are 1 through 4094. The default value is 1.
Note:
T
he port must be a member of the same VLAN as the Port
VLAN ID.
59
