Service and Repair Manual August 2021
Scissor Components
90 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
62 Place a 4 x 4 x 48 inch / 10 cm x 10 cm x
1.2 m long block across both sides of the
chassis under the number 1 center pivot pin
(index #7).
63 Attach a lifting strap from an overhead
supporting device to the number 1 inner arm
(index #8) at the non-steer end. Raise the
number 1 inner arm and remove the safety
arm. Lower the number 1 inner arm (index #8)
onto the block that was placed across the
chassis.
Bodily injury hazard. Keep
hands clear of moving parts
when lowering the scissor arms.
64 Remove the cables from the number 1 cable
bridge and lay them off to the side.
Component damage hazard.
Cables can be damaged if they
are kinked or pinched.
65 Support and secure the entry ladder to an
appropriate lifting device.
66 Remove the fasteners from the entry ladder
and remove the entry ladder from the
machine.
Crushing hazard. The entry
ladder will fall if not properly
supported and secured to the
lifting device.
67 Attach a lifting strap from an overhead
supporting device to the number 1 outer arm
(index #17). Do not apply any lifting pressure.
68 Remove the external snap rings and retaining
fasteners from the number 1 center pivot pins
(index #7).
69 Remove the number 1 cable bridge from the
machine.
70 Use a soft metal drift to remove the number
1 center pivot pins (index #7).
Bodily injury hazard. The
number
1 outer arm may
become unbalanced and fall if
not properly supported when the
pin is removed.
71 Slide the number 1 outer arm (index #17) to
the non-steer end and remove it from the
machine.
Bodily injury hazard. The
number
1 outer arm may
become unbalanced and fall if
not properly supported when
removed from the machine.
72 Attach the strap from an overhead supporting
device to the number 1 inner arm (index #8).
Do not lift it.
73 Remove the upper fasteners securing the
number 1 inner arm pivot bracket to the end
of the chassis. Loosen the lower fasteners.
74 Remove the number 1 inner arm (index #8)
from the machine.
Bodily injury hazard. The
number
1 inner arm may
become unbalanced and f
all if
not properly supported when
removed from the machine.
Component damage hazard. Be
sure not to damage the limit
switch or level sensor
components when the number
1
inner arm is removed from the
machine.
