Scissor Components
114 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
64 Attach a lifting strap from an overhead
supporting device to the number 2 outer arm
at the ground control side (index #19).
65 Remove the retaining fasteners from the
number 2 center pivot pin (index #7) at the
ground control side.
66 Place a rod through the number 2 center pivot
pin at the ground control side (index #7) and
twist to remove the pin.
67 Remove the retaining fasteners from the
number 2 pivot pin (index #20) at the non-
steer end.
68 Use a soft metal drift to remove the number
2 pivot pin (index #20) from the non-steer end
of the machine. Remove the number 2 outer
arm at the ground control side (index #19)
from the machine.
he number 2 outer arm at the
ground control side (index #19)
may become unbalanced and
fall if not properly supported
when the pivot pin is removed.
69 Attach a lifting strap from an overhead
supporting device to the number 2 outer arm
at the battery side (index #19).
70 Remove the retaining fasteners from the
number 2 center pivot pin (index #7) at the
battery side.
71 Place a rod through the number 2 center pivot
pin at the battery side (index #7) and twist to
remove the pin.
Crushing hazard. The number
2
outer arm (index #19) may
become unbalanced and fall if
not properly supported when the
pivot pin is removed.
72 Remove the number 2 outer arm (index #19)
from the machine.
Crushing hazard. The number
2
outer arm (index #19) may
become unbalanced and fall if
not properly supported when
removed from the machine.
73 Attach a lifting strap from an overhead
supporting device to the number 2 inner arm
(index #18). Raise the arm to a vertical
position.
74 Remove the retaining fasteners from the
number 2 pivot pin at the steer end of the
machine (index #8).
75 Use a soft metal drift to remove the number
2 pivot pin (index #8) from the steer end of the
machine. Remove the number 2 inner arm
(index #18) from the machine.
Crushing hazard. The number
2
inner arm (index #18) may
become unbalanced and fall if
not properly supported when the
pivot pin is removed.
76 Attach a lifting strap from an overhead
supporting device to the number 1 inner arm
(index #10).
77 Raise the number 1 inner arm (index #10)
approximately 2 feet / 60 cm.
78 Place a 4 x 4 x 48 inch / 10 cm x 10 cm x
1.2 m long block across both sides of the
chassis under the number 1 center pivot pin
(index #9).
79 Lower the scissor arms onto the block that
was placed across the chassis.
Bodily injury hazard. Keep
hands clear o
f moving parts
when lowering the scissor arms.
80 Attach a lifting strap from an overhead
supporting device to the lug of the rod end of
the lower lift cylinder.
