Terex Genie GS-1330m User Manual

August 2021 Service and Repair Manual
Scissor Components
Part No. 1309020GT GS
™
-30m • 32m • 30 • 32 • 46 • 55 115
81 Tag, disconnect and plug the hydraulic hose
on the lower lift cylinder. Cap the fittings on
the cylinder.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
82 Tag and disconnect the wire harness from the
solenoid valve on the cylinder.
83 Tag and disconnect the wires and manual
lowering cable from the solenoid valve on the
cylinder.
84 Tag and disconnect the wire harness from the
platform overload pressure transducer.
85 Raise the lift cylinder to a vertical position.
86 Remove the pin retaining fasteners from the
lift cylinder barrel-end pin (index #21). Use a
soft metal drift to remove the pin. Remove the
lift cylinder from the machine.
Crushing hazard. The lift
cylinder will fall if not properl
y
supported when the pivot pin is
removed.
Component damage hazard. Be
careful not to damage the valve
or fittings on the cylinder while
removing it from the machine.
87 Remove the cables from the number 1 cable
bridge and lay them off to the side.
Component damage hazard.
Cables can be damaged if they
are kinked or pinched.
88 Disconnect the number 1 cable bridge from
the number 1 outer arm (index #22) and
remove the cable bridge from the machine.
89 Attach a lifting strap from an overhead
supporting device to the number 1 inner arm
(index #10).
90 Raise the arm slightly and remove the block.
91 Lower the arm to the stowed position.
Bodily injury hazard. Keep
hands clear of moving parts
when lowering the scissor arms.
92 Secure the ends of the scissor arms together
at the steer end of the machine with a strap or
other suitable device.
93 Secure the ends of the scissor arms together
at the non-steer end of the machine with a
strap or other suitable device.
94 Remove the retaining fasteners securing the
chassis mount bracket to the chassis.
95 Remove the linkset from the machine
Bodily injury hazard. The
number
1 inner and outer arms
(index #1
0 and #22) may
become unbalanced and fall if
not properly supported when
removed from the machine.
Component damage hazard. Be
sure not to damage the limit
switch or level sensor
components when the number
1
inner and outer arms (index
#1
0 and #22) are removed from
the machine.
