Service and Repair Manual August 2021
Scissor Components
132 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
95 Remove the number 2 outer arm (index #31)
from the machine.
Crushing hazard. The number
2
outer arm (index #31) may
become unbalanced and fall if
not properly supported when
removed from the machine.
96 Attach a lifting strap from an overhead
supporting device to the number 2 inner arm
(index #30). Raise the arm to a vertical
position.
97 Remove the retaining fasteners from the
number 2 pivot pin at the steer end of the
machine (index #14).
98 Use a soft metal drift to remove the number
2 pivot pin (index #14) from the steer end of
the machine. Remove the number 2 inner arm
(index #30) from the machine.
Crushing hazard. The number
2
inner arm (index #30) may
become unbalanced and fall if
not properly supported
when the
pivot pin is removed.
99 Attach a lifting strap from an overhead
supporting device to the number 1 inner arm
(index #16).
100 Raise the number 1 inner arm (index #16)
approximately 2 feet / 60 cm.
101 Place a 4 x 4 x 48 inch / 10 cm x 10 cm x
1.2 m long block across both sides of the
chassis under the number 1 center pivot pin
(index #15).
102 Lower the scissor arms onto the block that
was placed across the chassis.
Bodily injury hazard. Keep
hands clear of moving parts
when lowering the scissor arms.
103 Attach a lifting strap from an overhead
supporting device to the lug of the rod end of
the lower lift cylinder.
104 Tag, disconnect and plug the hydraulic hose
on the lower lift cylinder. Cap the fittings on
the cylinder.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
105 Tag and disconnect the wire harness from
the solenoid valve on the cylinder.
106 Tag and disconnect the wires and manual
lowering cable from the solenoid valve on the
cylinder.
107 Tag and disconnect the wire harness from
the platform overload pressure transducer.
108 Raise the lift cylinder to a vertical position.
109 Remove the pin retaining fasteners from the
lift cylinder barrel-end pivot pin (index #28).
Use a soft metal drift to remove the pin.
Remove the lift cylinder from the machine.
Crushing hazard. The lift
cylinder will fall if not properly
supported when the pivot pin is
removed.
Component damage hazard. Be
careful not to damage the valve
or fittings on the cylinder while
removing it from the machine.
110 Remove the cables from the number 1 cable
bridge and lay them off to the side.
Component damage hazard.
Cables can be damaged if they
are kinked or pinched.
To Next Page
