August 2021 Service and Repair Manual
Scissor Components
Part No. 1309020GT GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 133
111 Remove the cables from the number 1 cable
bridge and lay them off to the side.
112 Disconnect the number 1 cable bridge from
the number 1 outer arm (index #34) and
remove the cable bridge from the machine.
113 Attach a lifting strap from an overhead
supporting device to the number 1 inner arm
(index #16).
114 Raise the arm slightly and remove the block.
115 Lower the arm to the stowed position.
Bodily injury hazard. Keep
hands clear of moving parts
when lower
ing the scissor arms.
116 Secure the ends of the scissor arms together
at the steer end of the machine with a strap or
other suitable device.
117 Secure the ends of the scissor arms together
at the non-steer end of the machine with a
strap or other suitable device.
118 Remove the retaining fasteners securing the
chassis mount bracket to the chassis.
119 Remove the linkset from the machine.
y hazard. The
1 inner and outer arms
6 and #34) may
become unbalanced and fall if
not properly supported when
removed from the machine.
Component damage hazard. Be
sure not to damage the limit
switch or level sensor
components when the n
umber
inner and outer arms (index
6 and 34) are removed from
