Table 6-13. Clock Domain Descriptions (continued)
CLOCK
DOMAIN
DEFAULT
SOURCE
SOURCE
SELECTION
REGISTER
SPECIAL CONSIDERATIONS
VCLKA1 VCLK VCLKASRC
• Defaults to VCLK as the source
• Is disabled through the CDDISx registers bit 4
RTICLK VCLK RCLKSRC
• Defaults to VCLK as the source
• If a clock source other than VCLK is selected
for RTICLK, then the RTICLK frequency must
be less than or equal to VCLK/3
– Application can ensure this by
programming the RTI1DIV field of the
RCLKSRC register, if necessary
• Is disabled through the CDDISx registers bit 6
