Manual 0-5057 3-1 INSTALLATION
PAK 200
CAUTION
Fuse and wire sizes are for reference only. The installation must conform to national and local codes
for the type and method of wire being used.
Gas Supply
The customer must supply all gases and pressure regulators. Gases must be of high quality. Pressure regulators
must be double-stage and installed as close as possible to the gas console. Contaminated gas can cause one or
more of the following problems:
• Reduced cutting speed • Poor cut quality
• Poor cutting precision • Reduced consumables life.
•
Oil or grease contamination from compressed
or bottled air can cause fires in conjunction with oxygen.
Cooling System Requirements
Coolant must be added to the system on installation. The amount required varies with torch leads length.
Thermal Dynamics recommends the use of its coolants 7-3580 and 7-3581 (for low temperatures).
SECTION 3:
INSTALLATION
3.01 Installation Requirements
Electric Supply
The electrical supply network, the gas and water supply system must meet local safety standards. This conformity
shall be checked by qualified personnel.
PAK 200 Power Supply
Input Power Input Current
Suggested Sizes
(See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph
208 60 47 130 160 #2
2
230 60 49 125 150 #2
2
400 50 54 77 100 #2
1
460 60 59 75 90 #2
1
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electrical Code
1
Extra Hard Usage Type SO, SOW, SOO, SOOW, ST, STW, STO, STOW, STOO, STOOW
2
Extra Hard Usage Type G, G-GC, W
Coolant Capabiities
Cat. Number and Mixture Mixture Protects To
7-3580 ‘Extra-CoolTM’ 25 / 75 10° F / -12° C
7-3581 ‘Ultra-CoolTM’ 50 / 50 27° F / -33° C
7-3582 ‘Extreme-CoolTM’ Concentrat* -65° F / -51° C
*For mixing with D-1 CoolTM 7-3583
