Thermal Dynamics PAK 200 User Manual

PAK 200
OPERATION 4-10 Manual
Type Torch: PCH-200 Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Air
Thickness Tip Output
Amper-
age
Speed
(Per Minute) Standoff
Plasma
Gas Press
Sec Gas
Press Total Flow (SCFH)
Pierce
Height
Inches mm (Cat. No.) Volts (VDC) (Amps) Inches Meters Inches mm psi bar psi bar Plasma Secondary Inches mm
0.032 0.8 32-1320 100 35 400 10.2 0.13 3.2 63 4.3 60 4.1 50 340 0.13 3.2
0.050 1.3 32-1320 100 35 250 6.4 0.13 3.2 63 4.3 60 4.1 50 340 0.13 3.2
0.063 1.6 32-1320 100 35 125 3.2 0.13 3.2 63 4.3 60 4.1 50 340 0.13 3.3
0.091 2.3 32-1320 110 35 90 2.3 0.13 3.2 63 4.3 60 4.1 50 340 0.13 3.3
0.125 3.2 32-1320 115 35 60 1.5 0.13 3.3 63 4.3 60 4.1 50 340 0.13 3.3
0.063 1.6 32-1321 118 70 200 5.1 0.13 3.3 50 3.4 60 4.1 60 332 0.13 3.3
0.125 3.2 32-1321 125 70 125 3.2 0.13 3.3 70 4.8 60 4.1 82 332 0.13 3.3
0.188 4.8 32-1321 125 70 85 2.2 0.13 3.3 70 4.8 60 4.1 82 332 0.13 3.3
0.25 6.4 32-1321 130 70 65 1.7 0.13 3.3 70 4.8 60 4.1 82 332 0.13 3.3
0.375 9.5 32-1321 140 70 25 0.6 0.13 3.3 70 4.8 60 4.1 82 332 0.25 6.4
0.500 12.7 32-1321 145 70 15 0.4 0.13 3.3 70 4.8 60 4.1 82 332 0.25 6.4
0.25 6.4 32-1322 125 120 125 3.2 0.19 4.7 60 4.1 60 4.1 78 340 0.25 6.4
0.375 9.5 32-1322 130 120 70 1.8 0.19 4.8 60 4.1 60 4.1 78 340 0.25 6.4
0.500 12.7 32-1322 145 120 35 0.9 0.19 4.8 60 4.1 60 4.1 78 340 0.25 6.4
0.625 15.9 32-1322 150 120 30 0.8 0.19 4.8 60 4.1 60 4.1 78 340 0.38 9.7
0.750 19.1 32-1322 160 120 20 0.5 0.19 4.8 60 4.1 60 4.1 78 340 0.38 9.7
0.500 12.7 32-1323 165 200 90 2.3 0.15 3.8 70 4.8 60 4.1 83 340 0.40 10.2
0.750 19.1 32-1323 170 200 55 1.4 0.18 4.6 70 4.8 60 4.1 83 340 0.45 11.4
Type Torch: PCH-200 Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Air
Thickness Tip
Output
Volts
Amper-
age
Speed (Per
Minute) Standoff
Plasma Gas
Press
Sec Gas
Press Total Flow (SCFH) Pierce Height
Inches mm (Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi bar psi bar Plasma Secondary Inches mm
20 ga. 0.9 32-1320 110 35 100 2.5 0.13 3.2 65 4.5 60 4.1 50 340 0.13 3.3
18 ga. 1.2 32-1320 110 35 50 1.3 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
0.063 1.6 32-1320 110 35 40 1.0 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
0.125 3.2 32-1320 110 35 30 0.8 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
0.188 4.8 32-1320 110 35 20 0.5 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
0.063 1.6 32-1321 120 70 225 5.7 0.13 3.2 70 4.8 60 4.1 80 340 0.13 3.3
0.125 3.2 32-1321 120 70 135 3.4 0.13 3.2 70 4.8 60 4.1 80 340 0.13 3.3
0.188 4.8 32-1321 120 70 100 2.5 0.13 3.3 70 4.8 60 4.1 80 340 0.13 3.3
0.250 6.4 32-1321 125 70 65 1.7 0.13 3.3 70 4.8 60 4.1 80 340 0.13 3.3
0.375 9.5 32-1321 130 70 30 0.8 0.13 3.3 70 4.8 60 4.1 80 340 0.25 6.4
0.500 12.7 32-1321 140 70 20 0.5 0.19 4.7 70 4.8 60 4.1 80 340 0.25 6.4
0.250 6.4 32-1322 130 120 135 3.4 0.19 4.8 75 5.2 60 4.1 90 340 0.25 6.4
0.375 9.5 32-1322 130 120 80 2.0 0.19 4.8 75 5.2 60 4.1 90 340 0.25 6.4
0.500 12.7 32-1322 135 120 40 1.0 0.19 4.8 75 5.2 60 4.1 90 340 0.25 6.4
0.625 15.9 32-1322 140 120 30 0.8 0.19 4.8 75 5.2 60 4.1 90 340 0.25 6.4
0.750 19.1 32-1322 145 120 25 0.6 0.19 4.8 75 5.2 60 4.1 90 340 N/R N/R
1.250 31.8 32-1322 160 120 10 0.3 0.19 4.8 75 5.2 60 4.1 90 340 N/R N/R
0.500 12.7 32-1323 150 200 110 2.8 0.2 5.1 70 4.8 60 4.1 85 340 0.40 10.2
0.750 19.1 32-1323 165 200 35 0.9 0.2 5.1 70 4.8 60 4.1 85 340 0.50 12.7
4.07 Recommended Cutting Speeds
