PAK 200
Manual 0-5057 4-11 OP-
Type Torch: PCH-200 Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Air
Thickness Tip
Output
Volts
Amper-
age
Speed
(Per Minute) Standoff
Plasma Gas
Press
Sec Gas
Press Total Flow (SCFH) Pierce Height
Inches mm (Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi bar psi bar Plasma Secondary Inches mm
21 ga 0.8 32-1320 95 35 400 10.2 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
18 ga 1.2 32-1320 100 35 300 7.6 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
16 ga 1.5 32-1320 100 35 275 7 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
13 ga 2.2 32-1320 105 35 150 3.8 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
11 ga 2.9 32-1320 110 35 90 2.3 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
7 ga 4.8 32-1320 110 35 60 1.5 0.13 3.3 65 4.5 60 4.1 50 340 0.13 3.3
0.125 3.2 32-1321 120 70 180 4.6 0.19 4.8 70 4.8 60 4.1 77 340 0.25 6.4
0.188 4.8 32-1321 120 70 140 3.6 0.19 4.8 70 4.8 60 4.1 77 340 0.25 6.4
0.250 6.4 32-1321 122 70 75 1.9 0.19 4.7 70 4.8 60 4.1 77 340 0.25 6.4
0.375 9.5 32-1321 125 70 55 1.4 0.19 4.8 70 4.8 60 4.1 77 340 0.25 6.4
0.500 12.7 32-1321 132 70 35 9 0.19 4.8 70 4.8 60 4.1 77 340 0.25 6.4
0.250 6.4 32-1322 125 120 125 3.2 0.25 6.4 65 4.5 60 4.1 78 340 0.38 9.7
0.375 9.5 32-1322 130 120 80 2 0.25 6.4 65 4.5 60 4.1 78 340 0.38 9.7
0.500 12.7 32-1322 135 120 55 1.4 0.25 6.4 65 4.5 60 4.1 78 340 0.38 9.7
0.625 15.9 32-1322 140 120 40 1 0.25 6.4 65 4.5 60 4.1 78 340 0.38 9.7
0.750 19.1 32-1322 145 120 30 0.8 0.25 6.4 65 4.5 60 4.1 78 340 0.38 9.7
1.000 25.4 32-1322 160 120 15 0.4 0.25 6.4 65 4.5 60 4.1 78 340 N/R N/R
1.250 31.8 32-1322 165 120 12 0.3 0.25 6.4 65 4.5 60 4.1 78 340 N/R N/R
1.500 38.1 32-1322 180 120 5 0.1 0.25 6.4 62 4.3 60 4.1 78 340 N/R N/R
0.50 12.7 32-1323 144 200 85 2.2 0.15 3.8 70 4.8 60 4.1 83 340 0.30 7.6
0.75 19.05 32-1323 150 200 50 1.3 0.18 4.6 70 4.8 60 4.1 83 340 0.35 8.9
1.00 25.4 32-1323 158 200 30 0.8 0.25 6.4 70 4.8 60 4.1 83 340 0.40 10.2
1.50 38.1 32-1323 168 200 15 0.4 0.25 6.4 70 4.8 60 4.1 83 340 N/R N/R
2.00 50.8 32-1323 188 200 10 0.3 0.25 6.4 70 4.8 60 4.1 83 340 N/R N/R
Type Torch: PCH-200 Type Material: Stainless Steel
Type Plasma Gas: Ar-35H2 Type Secondary Gas: Nitrogen
Thickness Tip
Output
Volts
Amper-
age
Speed
(Per Minute) Standoff
Plasma Gas
Press
Sec Gas
Press Total Flow (SCFH) Pierce Height
Inches mm (Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi bar psi bar Plasma Secondary Inches mm
0.750 19.1 32-1322 140 120 20 0.5 0.19 4.8 62 4.3 60 4.1 78 340 0.40 10.2
1.000 25.4 32-1322 145 120 15 0.4 0.19 4.8 62 4.3 60 4.1 78 340 N/R N/R
1.250 31.8 32-1322 150 120 10 0.3 0.19 4.8 62 4.3 60 4.1 78 340 N/R N/R
1.500 38.1 32-1322 155 120 7 0.2 1.9 48.3 62 4.3 60 4.1 78 340 N/R N/R
0.500 12.7 32-1323 155 200 50 1.3 0.27 6.9 70 4.8 60 4.1 84 340 0.40 10.2
0.750 19.1 32-1323 160 200 30 0.8 0.3 7.6 70 4.8 60 4.1 84 340 0.50 12.7
