Thermal Dynamics PAK 200 - Page 54

PAK 200
OPERATION 4-12 Manual
Type Torch: PCH-200 Type Material: Aluminum
Type Plasma Gas: Ar-35H2 Type Secondary Gas: Nitrogen
Thickness Tip
Output
Volts
Amper-
age
Speed (Per
Minute) Standoff
Plasma Gas
Press Sec Gas Press Total Flow (SCFH) Pierce Height
Inches mm (Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi bar psi bar Plasma Secondary Inches mm
0.250 6.4 32-1322 130 120 100 2.5 0.25 6.4 65 4.5 60 4.1 75 340 0.25 6.4
0.500 12.7 32-1322 135 120 60 1.5 0.25 6.4 65 4.5 60 4.1 75 340 0.38 9.7
0.750 19.1 32-1322 135 120 30 0.8 0.25 6.4 65 4.5 60 4.1 75 340 0.38 9.7
1.000 25.4 32-1322 140 120 20 0.5 0.25 6.4 65 4.5 60 4.1 75 340 N/R N/R
0.500 12.7 32-1323 145 200 110 2.8 0.3 7.6 70 4.8 60 4.1 82 340 0.40 10.2
0.750 19.1 32-1323 150 200 50 1.3 0.4 10.2 70 4.8 60 4.1 82 340 0.45 11.4
