INSTALLATION 3-10 Manual 0-5057
PAK 200
3.08 Connect Torch Control Cable
1. Connect the Torch Control cable to the power supply receptacle marked ‘J15’.
RETURN
SUPPLY
RETURN
SUPPLY
Art # A-08492
To Torch
