Manual 0-5057 3-3 INSTALLATION
PAK 200
3.03 Cables and Leads Identification
G
Torch Lead Set
Art # A-08377_AC
Green / Yellow #4 AWG
A
Green
Red
#8 AWG Cable
#1 AWG Cable
B
C
D
E
F
K
Work Cable
37
14
Coolant Leads, Power Supply
to Arc Starter
Pilot Return, Power Supply
to Arc Starter
Negative Lead, Power Supply
to Arc Starter
Control Cable, Power Supply
to Arc Starter
Ground Cable
O
Control Cable,
Power Supply to
Gas Control Module
Green
Red
4’ / 1.3 m
#1 AWG
