Manual 0-5057 3-9 INSTALLATION
PAK 200
3.07 Connect Gas Supply Lines
1. Connect the gas supply lines to the appropriate input ports as shown.
RETURN
SUPPLY
RETURN
SUPPLY
Art # A-08463
Plasma Gas - In
Shield Gas - In
