Thermal Dynamics PAK 200 - Optional Gas Supply Leads

Manual 0-5057 6-5 PARTS LIST
PAK 200
6.05 Optional Gas Supply Leads
HOSE ASSEMBLIES
Lengh (feet) 10’ 15’ 25’ 35’ 50’ 75’ 100’
Length (meters) 3.05 4.6 7.6 10.6 15.2 22.9 30.4
1/4”
Inert B (RH) 9-2146 9-5061 9-5073 9-5085 9-5097 9-5109 9-5121
02 B (RH) 9-9008 9-9009 9-9010 9-9011
3/8”
Inert B (RH)
Inert B (LH) 9-9012 9-9013 9-9014 9-9015
SYNFLEX HOSE FITTINGS
ID
CATALOG #
per foot
NUT
Inert B
(LH)
NUT
Inert B
(RH)
NIPPLE
Inert
NUT
FUEL B
(LH)
NUT
02 B
(RH) NIPPLE CLAMP
1/4” 9-3743 9-3556 9-2776 9-2775 8-5518 8-5015 8-0327 8-0384
3/8” 9-3616 8-6473 N/A N/A N/A 8-6617 N/A 8-0384
1/2” 9-2551 8-6470 N/A N/A 9-3831
ADAPTER FITTINGS Catalog #
1/4” NPT
Inert B (RH) 8-0330
Inert B (LH) 8-0329
02 B (RH) 8-0260
1/4” Barb 8-4264
