Engine Maintenance
115
1. Restraining Bracket 14. Mount Screw
Bracket Screw 15. Flatwasher
Belleville Washer 16. Wear Plate Mount
Nut Wear Plate Rivet
2. Nut 17. Engine Screw
3. Belleville Washer 18. Belleville Washer
4. Vibration Mount 19. Vibration Engine Mount (set of two)
5. Engine Mount (roadside) 20. Nut
6. Engine Mount (curbside) Thread (Blue) Sealer
7. Engine Mount (upper) 21. Vibration Mount
Screw (socket head, 10 x 1.5, 25 mm lg) 22. Bracket
Screw (socket head, 10 x 1.25, 20 mm lg) 23. Stud
Screw (hex head, 10 x 1.25, 20 mm lg) 24. 3-Link Chain
Belleville Washer 25. Eye Bolt
8. Engine Mount (front) 26. Mount Screw
Mount Screw Flatwasher
Flatwasher Nut
Belleville Washer 27. Nut
Nut 28. Flatwasher
9. Vibration Mount 29. Lockwasher
10. Engine Screw 30. Nut
11. Engine Screw 31. Gauge Bracket
12. Special Washer 32. Chain Screw
13. Special Washer
TK 3.95 Engine Mounting Components for Figure 142
