Remote Evaporator Maintenance Inspection

Schedule

Pre-Trip

Every

1,500

Hours

Annual /

4,500

Hours

Inspect/Service These Items

Electrical

• • Inspect wire harness for damaged wires or connections.

• • Inspect/replace fan motor brushes.

Structural

• • • Visually inspect unit for fluid leaks.

• • • Visually inspect unit for damaged, loose or broken parts.

• • Clean entire unit including evaporator coils and defrost drains.

• Check all unit mounting bolts, brackets, lines, hoses, etc.
