21
Specifications
Engine
Model: Ending First Quarter 2006
Starting First Quarter 2006
TK 3.95
TK376
See “Engine” on page 28 to identify the engine in the
unit.
Fuel Type No. 2 Diesel fuel under normal conditions
No. 1 Diesel fuel is acceptable cold weather fuel
Oil Capacity: Crankcase & Oil Filter 12 quarts (11.2 liters)
w/Bypass Oil Filter 13 quarts (12.3 liters) Fill to full mark on dipstick
Oil Type API Classification CI-4 or better recommended
(ACEA Rating E3 or better for Europe)
API Synthetic Classification CI-4 (ACEA Rating E3 for
Europe) or better after first 500 hours (optional)
Oil Viscosity Multigrade Oil Ambient Temperature
SAE 5W-30 -22 to +32 F (-30 to 0 C)
SAE 10W-30 -13 to +86 F (-25 to +30 C)
SAE 10W-40 -13 to +104 F (-25 to +40 C)
SAE 15W-40 +5 to +122 F (-15 to +50 C)
Engine RPM: Low Speed Operation
High Speed Operation
1800 ± 25 RPM
2425 ± 25 RPM
Engine Oil Pressure: TK 3.95
TK376
35 to 60 psig (241 to 414 kPa)—high speed
40 to 60 psig (276 to 414 kPa)—high speed
Intake Valve Clearance 0.006 to 0.010 in. (0.15 to 0.25 mm)
Exhaust Valve Clearance 0.006 to 0.010 in. (0.15 to 0.25 mm)
Valve Setting Temperature Room temperature
Timing Injection Pump 16 degrees BTDC
Injection Nozzle Pressure: TK 3.95
TK376
1700 psig (11721 kPa)
1711 to 1856 psig (11800 to 12800 kPa)
Low Oil Pressure Switch 10 ± 2 psig (69 ± 14 kPa)—shutdown
High Coolant Temperature Sensor 220 ± 5 F (104 ± 3 C)—shutdown
Engine Thermostat 180 F (82 C)
