Specifications
22
Engine Coolant Type ELC (Extended Life Coolant), which is red. Units
equipped with ELC have an ELC nameplate on the
expansion tank. Use a 50/50 concentration of any of
the following equivalents:
Cheveron Dex-Cool
Texaco ELC
Havoline Dex-Cool®
Havoline XLC for Europe
Shell Dexcool®)
Shell Rotella
Saturn/General Motors Dex-Cool®
Caterpillar ELC
Detroit Diesel POWERCOOL® Plus
CAUTION: Do not mix conventional (green or
blue-green) coolant and ELC except in an
emergency. If conventional coolant is added to
Extended Life Coolant, the coolant must be
changed after 2 years instead of 5 years.
Coolant System Capacity 4.0 qts (3.8 liters) with overflow tank
Radiator Cap Pressure 10 psig (69 kPa)
Engine (Continued)
Belt Tension
Belt Tension on TK Gauge (See Tool Catalog)
New Belt Field Reset
Engine/Electric Motor (Jackshaft) Reading on bottom
span between engine and electric motor
55 to 65 55 to 60
Electric Motor (Jackshaft)/Compressor Reading
between electric motor and alternator (or 1/4 in.
deflection with 10 lb pressure)
55 to 60 55 to 60
Water Pump 40 40
NOTE: Use belt tension gauge (P/N 204-427) whenever possible to check belt tension.
New belts should be tensioned cold and tensioned cold again after 10 hours of unit operation.
