Thermo King SPECTRUM TS Series User Manual

Specifications
24
System Controller
Type SPECTRUM™ TS Microprocessor Controller
Electrical Components
Current Draw (Amps)
at 12.5 Vdc
Resistance
(Ohms)
Glow Plug TK 3.95
TK376
8.3
4.3
1.5 ± 0.15
2.3 ± 0.2
Fuel Solenoid: Pull In
Hold In
35 to 45
0.5
0.2 to 0.3
24 to 29
Starter Motor 90 to 105 (cranking)
High Speed Solenoid 2.9 4.3
High Speed (Throttle) Solenoid: TK 3.95
TK376
2.9
3.3
4.3
3.8
Condenser Inlet Solenoid 22 Watt 1.76 7.1
Purge Valve 15 Watt 1.20 10.4
Liquid Injection Solenoid 13 Watt 1.04 12.0
Hot Gas Bypass Solenoid 10 Watt 0.80 15.6
Hot Gas Solenoids 18 Watt 1.4 8.7
Liquid Line Solenoids 15 Watt 1.20 10.4
Suction Line Solenoids 18 Watt 1.4 8.7
NOTE: Disconnect components from unit circuit to check resistance.
Electric Standby (Model 50 Unit Only)
Voltage/Phase/ Frequency Horsepower Kilowatts RPM Full Load
Amps
Locked Rotor
Amps
Overload
Relay Setting
Amps
220/3/50 10 7.5 1455 25.1 116 32
230/3/60 12 8.9 1750 28.8 123 32
380/3/50 10 7.5 1455 14.5 58 16
460/3/60 12 8.9 1750 14.4 62 16
Standby Power Requirements
Supply Circuit Breaker: 50 amp/220-230 volts
20 amp/380-460 volts
Extension Cord Size: Up to 50 ft—10 gauge
75 ft—8 gauge
