Thomas 85 - Steering 4.1

4-2
4
STEERING 4.1
1
7
8
8
3
16
9
10
11
5
4
9
11
13
15
14
16
13
19
17
6
19
18
12
17
Up To LB003362
2
C5568
1 Left Control Lever
2 Handle
3 Right Control Lever
4 Bolt
5 Washer
6 Boot
7 Plate
8 Hydroback Assembly
9 Bushing Spacer
10 Nut
11 Pintle Lever
12 Split Pin
13 Right Control Rod
14 Left Control Rod
15 Rod End
16 Set Collars
18
17 Control Rate Limiter
18 Bushing, Isolator
19 Isolator
