AXLE ASSEMBLY 3.5
Axle Assembly 85
1 Axle 7 Bearing 13. Drive sprocket
2 Nut 8 Sprocket 14. Chain
3 Stud 9 Axle spacer 15. Chain
4 Key 10 Nut
5 Seal 11 Cotter pin
6 Bearing 12 Drive sprocket nut
