Thomas 85 - Throttle

4-17
4
1. Throttle knob
2. Throttle handle
3. Boot
4. Bolt
5. Friction pad
6. Nut
7. Flat washer
8. Spring
9. Collar
10. Throttle rod
11. Nut
12. Rod end assy.
13. Lock washer
14. Nut
THROTTLE 4.4
19
23
14
15
14
13
18
15
17
16
11
12
13
14
21
22
24
26
25
13
27
12
11
20
27
4
5
9
10
6
7
8
7
3
2
1
15. Washer
16. Flat washer
17. Bolt
18. Throttle crank sheet
19. Throttle rod engine bar
20. Clip
21. Nut
22. Flat washer
23. Bolt
24. Throttle bracket plate
25. Lock washer
26. Bolt
27. Bolt
C2797
