Lubrication System (cont’d)
7 Remove the oil fill cap located in the engine rocker
arm cover. (fig. C5116) Add 3.75 qts (3.5 liters) of 5W40
API classification CG-4 or better engine oil. Replace the
fill cap in the rocker arm cover.
7-3
7
9 Check the level of the engine oil. (fig. C5641) Add
oil as required to bring the oil to the top mark of the
engine oil dip stick. (fig. C2633) Do not over fill.
Change the engine oil and filter initialy at 50 hours and
then every 100 hours.
8 Start the engine and check for leaks around the oil
filter and oil pan drain plug. (fig. C5185) Allow the
engine to operate for approximately 5 minutes and then
shut it off.
ENGINE MAINTENANCE 7.1
C5116
Engine oil fill cap
C5641
Engine oil level
dip stick location
C5185
Check for leaks
C2633
Full level
Low level (add)
Engine oil level dip stick markings
