Fuel System (cont’d)
Bleeding the Fuel System:
If the loader has been run dry of fuel, or the fuel filter
has been changed, it may be necessary to bleed the air
from the fuel lines.
1 Replenish the fuel reservoir (tank) with a minimum
of 10 gallons (45 liters) of fuel.
2 Make sure the fuel line shut off petcock is fully
open. (fig. C5186)
7-5
7
4 Loosen the air bleed petcock located to the left of
the fuel injection pump. (fig. C5285)
5 Turn the engine over with the starter until the
engine starts to smoke. Do not engage the starter for
more than 15 second intervals. Allow the starter to cool
between starting attempts for 1 (one) minute.
6 Pre- heat the and start engine. (If engine fails to
start, proceed to step 7.) Allow the engine to operate at
an idle speed for 5 minutes. Shut off the engine.
7 Close the air bleed petcock.
3 Loosen the fuel filter bleeder bolt and allow the
fuel to siphon through the fuel line and filter. (fig.
C5643) Tighten the fuel filter bleeder bolt.
ENGINE MAINTENANCE 7.1
C5186
C5643
C5285
Engine air bleed petcock
Bleeder bolt
If the engine still will not start, the injector lines will
have to be bled.
8 Using a wrench to steady the injector, loosen the
injector lines at each injector one half turn.
9 Turn the engine over until fuel seeps out around
the nuts.
10 Tighten the injector nuts. Pre-heat and start the
engine.
C5644
Loosen nuts
