Air Filter (cont’d)
4 After removing the air filter element, carefully wipe
out any excess dirt from the air cleaner housing.
(fig. C5286)
5 Check the air filter element seal before installing to
the air cleaner housing. (fig. C5279) Be sure the seal is
not damaged, torn or gouged. Do not use a filter with a
damaged seal.
6 When installing the air filter element to the air clean-
er housing. support the back of housing with one hand
and push the air filter element into position as gently as
possible.
7 Install wing nut. Do not use the wing nut to pull
the filter element into place.
8 Install the air cleaner cover onto the housing, tighten
band clamp.
9 Reset the service indicator. (fig. C5118)
7-7
7
ENGINE MAINTENANCE 7.1
C5286
C5279
Seal
Wipe
clean
C5118
Push to reset
