THOMSON RD1000 - Appendix C.e. GPIO Module - Option NRD00 H10 AA; Appendix C.f. Dual Input COFDM Receiver - Option NRD00 H04 AA

Page 104
THOMSON RD1000 / RD1002
Edition 2 – October 2010
Receiver Descrambler - User Manual (release 7.3.1)
Appendix C.e. GPIO Module – Option NRD00H10AA
ROHS Compliant
Yes
General –
Remote Interfaces:
Web GUI and SNMP
+Vcc Voltage Level
+5 @ 800 mA
Relay Type:
High-cycle, High-reliability
Contact Ratings:
>30 VDC @ 500 mA
Event Types:
OON (Out-Of-Network) and RTN (Return-To-Network)
Suggested Connector Type:
Phoenix 2.5 mm Pluggable Terminal Block
I/O –
Logic Input:
Provides four logic inputs
Logic Outputs:
Provides three open-collector outputs
Voltage Range:
5 – 24 volts logic switching and current limiting
Short circuit protection:
Yes
Relay Contact:
Provides three relay contact outputs
Appendix C.f. Dual Input COFDM Receiver – Option NRD00H04AA
ROHS Compliant
Yes
General –
Compatibility Standard:
EN 300 744
Spectrum:
Normal or Inverted
Frequency range:
49 MHz – 861 MHz
Channel bandwidth:
6 MHz, 7 MHz, 8 MHz
Guard interval:
1/4, 1/8, 1/16, 1/32
FFT size:
2K, 8K
Code rate:
1/2, 2/3, 3/4, 5/6, 7/8
Constellation:
QPSK, QAM16, QAM64
Connector:
2-F-81 Type, panel mount, female
Impedance:
75 Ohms
Return Loss:
>9 dB
