4.4 Exchanging the line fuse
ITC500 / page 101
4.4 Exchanging the line fuse
If the line fuse should have blown due to line disturbances, incorrectly set voltage or
other influences from the outside, it can be exchanged at the rear without opening
the unit.
Attention
To avoid fire hazard only the appropriate fuse for the corresponding
line voltage must be used (ITC502 and ITC510):
100V / 115V : T4H250V
230V : T2H250V
(IEC 60127-2/V, 5 x 20mm, 250V, slow response)
mains plug with fuse and spare fuse
Figure 17 Rear view of the ITC5xx
TEMP OUTAUX
