3.1 IEEE488 Interface
ITC500 / page 56
3.1 IEEE488 Interface
The IEEE488 interface of the ITC5xx-IEEE is based on the IEEE488.2 standard. This
includes the IEEE488.1 standard for the hardware settings. There is a standard 24-
pin IEEE488 jack at the rear of the unit. The address of the ITC5xx must differ from
that of other devices on the IEEE488 bus.
 (Please refer to chapter 3.1.2, “Setting up the Interface“, starting on page 57)
3.1.1 Interface specifications
Function Part set
Source Handshake SH1
Acceptor Handshake AH1
Talker T6
Listener L4
Service Request SR1
Remote/Local RL1
Parallel Poll PP0
Device Clear DC1
Device Trigger DT0
Electrical Interface E1
