3.1 IEEE488 Interface
ITC500 / page 58
Address
SW5
SW4
SW3
SW2
SW1
16
On
Off
Off
Off
Off
17
On
Off
Off
Off
On
18
On
Off
Off
On
Off
19
On
Off
Off
On
On
20
On
Off
On
Off
Off
21
On
Off
On
Off
On
22
On
Off
On
On
Off
23
On
Off
On
On
On
24
On
On
Off
Off
Off
25
On
On
Off
Off
On
26
On
On
Off
On
Off
27
On
On
Off
On
On
28
On
On
On
Off
Off
29
On
On
On
Off
On
30
On
On
On
On
On or Off
NOTE
The device address is valid after
switching off and on again.
String Terminator
The string terminator of the ITC5xx is pres
et to <LF><EOI>. This is fixed and cannot
be changed.
The ITC5xx will accept any combination of <LF> and <EOI> as string terminator.
