FFS2000 Series Chapter 5: Software
Rev B, July 21, 2017 Page 17
Chapter 5 Software
5.1. Software Interface
The GUI is the main window when working on the FFS2000 Series. It has different menus and toolbars that are
explained further later in this document. The buttons are described from top to bottom. The FFS3 graphical user
interface is illustrated below.
Figure 13 FFS3 Graphical User Interface
The top of the GUI contains a menu bar, a command bar, a camera bar, a processes bar, a macro bar, and a
toolbar containing control buttons. The center region of the GUI contains a live image captured by the CCD. The
bottom of the GUI contains control boxes for manipulating the fiber handlers and the splice head, as well as a
status bar.
The following sections detail the functions of the GUI.
5.2. Menu bar
Figure 14 Menu Bar
Menu
Bar
Camera Bar
Command
Process Bar
Macro Bar
Buttons
Captured by
the Camera
Control
Boxes
Status Bar
