FFS2000 Series Chapter 12: Specifications
Rev B, July 21, 2017 Page 81
12.2. FFS2000 Specifications
Fiber Specifications
Accepted Fiber Cladding
Diameters
80 to 200 µm
Fiber Type
SM or MM
12.3. FFS2000PT Specifications
Fiber Specifications
Accepted Fiber Cladding
Diameters
80 to 200 µm
Fiber Type
SM or MM
Proof Testing
Maximum Tension
7
89 N (20 lbs)
Mandrel Size
Ø2" (Ø50.8 mm)
Accuracy
±2%
12.4. FFS2000PM Specifications
Fiber Specifications
Accepted Fiber Cladding
Diameters
80 to 200 µm
Fiber Type
SM, MM, or PM
PM Rotation Specifications
Rotation Alignment
Fully Automated by End-View Alignment Technology or External
Feedback
Rotation Resolution
Stepper Motor Controller (0.01° Resolution)
Rotation Travel
190°
Extinction Ratio
-35 dB (Typical)
7
The proof tester is calibrated using standard weights that are hung off a pulley, so the tension settings are programmed in grams. This
maximum tension corresponds to 9.1 kg.
