Toa A-9120DHM2 - Dimensional Diagrams; AN-9001 Dimensions

123
17.1. AN-9001
17. DIMENSIONAL DIAGRAMS
Unit: mm (in)
1-gang Electrical Box
(not supplied)
31 (1.22)
37 (1.46)
70 (2.76)
ø130 (5.12)
83.5 (3.29)
90 – 98
(3.54 – 3.86)
42 (1.65)
38 (1.5)
46 – 50
(1.81 – 1.97)
[Front]
[Bottom]
[Side]
[Front view of Main unit]
[Figure when mounted] [Dimensions of
mounting opening]
Lock
Release
70 (2.76)
70 (2.76)
83.5 (3.29)
104 (4.09)
