25. SPEAKER PRESET PARAMETER LIST
Described here are parameters that can be used for the speaker parameter presetting screen (p. 67 and 69).
Depending on the speaker models such as F-1000, F-1300, F-2000, and SR-T5, "ALL FLAT" parameter is
recommended to be set as general use. However, set EQ parameters according to the installation
environment.
F-122 F-122 LOWCUT*
1
GAIN (dB) FREQ (Hz) Q GAIN (dB) FREQ (Hz) Q
HPF 37.5 0.5 HPF 45 0.5
HPF 37.5 0.7 HPF 45 0.7
+11.5 85 2.871 +6.5 80 1.414
–2.5 212 0.667 –4.5 180 0.667
–8 900 2.871 –8 900 2.871
+8 10 k 0.267 +8 11.2 k 0.267
LPF 20 k 0.7 LPF 20 k 0.7
Settable EQ bands Settable EQ bands
in the EQ setting screen in the EQ setting screen
EQ 01
EQ 02
EQ 03
EQ 04
EQ 05
EQ 06
EQ 07
EQ 08
EQ 09
EQ 10
H-1 H-1 LOWCUT*
1
GAIN (dB) FREQ (Hz) Q GAIN (dB) FREQ (Hz) Q
HPF 118 0.707 HPF 118 0.707
+10 125 1.8 +4 125 1.8
–6.5 220 1.414 –6.5 220 1.414
+1.5 5 k 0.305 +1.5 5 k 0.305
LPF 15.8 k 0.5 LPF 15.8 k 0.5
Settable EQ bands Settable EQ bands
in the EQ setting screen in the EQ setting screen
EQ 01
EQ 02
EQ 03
EQ 04
EQ 05
EQ 06
EQ 07
EQ 08
EQ 09
EQ 10
H-2 H-2 LOWCUT*
1
GAIN (dB) FREQ (Hz) Q GAIN (dB) FREQ (Hz) Q
HPF 63 0.707 HPF 63 0.707
+10 100 1.871 +2.5 100 1.871
–5 200 1.414 –5 200 1.414
+1.5 5 k 0.305 +1.5 5 k 0.305
LPF 15.8 k 0.5 LPF 15.8 k 0.5
Settable EQ bands Settable EQ bands
in the EQ setting screen in the EQ setting screen
EQ 01
EQ 02
EQ 03
EQ 04
EQ 05
EQ 06
EQ 07
EQ 08
EQ 09
EQ 10
*
1
Combination of specified speaker and subwoofer
