Toa A-9120DHM2 - Optional Modules Specifications

151
+24 V DC, –24 V DC, +6 V DC
20 mA (at +24 V DC), 20 mA (at –24 V DC), 60 mA (at +6 V DC)
2 channels,
3 kΩ (when the phantom power is ON) / 10 kΩ (phantom power is OFF),
electronically-balanced, removable terminal block (3 pins)
–60, –54, –48, –42, –36, –30, –24, –18, –10 dB* (selectable)
20 Hz – 20 kHz +1, –3 dB
0.008% (at 1 kHz, 20 – 20,000 Hz BPF, Input sensitivity: –10 dB)
Under –112 dB
(at 20 Hz – 20 kHz BPF, Input short, Input sensitivity: –60 dB)
Over 73 dB
(at 20 Hz – 20 kHz BPF, Input short, Input sensitivity: –10 dB)
Over 75 dB (at 20 kHz, Input sensitivity: –10 dB)
Over 62 dB (at 1 kHz, Input sensitivity: –60 dB)
24 bit Δ∑ADC
48 kHz
Bass: ±12 dB (at 100 Hz)
Treble: ±12 dB (at 10 kHz)
10 bands, Frequency: 20 Hz – 20 kHz, 31 steps, Variable range: ±12 dB,
Q: 0.3 – 5
–12 dB/oct, Variable frequency range: 20 – 400 Hz, 14 steps
–12 dB/oct, Variable frequency range: 4 – 20 kHz, 8 steps
Depth: 1 – 5
+24 V DC
–10 to +40°C (14 – 104°F)
Panel: Aluminum, hair-line
35 (w) x 78 (h) x 91.5 (d) mm (1.38" x 3.07" x 3.6")
82 g (0.18 lb)
26.5. Optional Modules
26.5.1. D-001T
Power Source
Current Consumption
Input
Input Sensitivity
Frequency Response
Total Harmonic Distortion + N
Input Equivalent Noise
S/N Ratio
Cross Talk
CMRR
A/D Converter
Sampling Frequency
Tone Control
Parametric Equalizer
High-pass Filter
Low-pass Filter
Compressor
Phantom Power
Operating Temperature
Finish
Dimensions
Weight
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Removable terminal plug (3 pins) .................... 2
Machine screw M3 x 8 ..................................... 2
