Toa A-9120DHM2 - Zm-9013

127
50.5 (1.99)
40.5
(1.59)
7
(0.28)
88 (3.46)
84.5 (3.33)
70 (2.76)
120 (4.72)
66 (2.6)
97 (3.82)
127 (5)
46 (1.81)
66 (2.6)
99 (3.9)
79 (3.11)
83.5 (3.29)
66 (2.6)
97 (3.82)
104 (4.09)
2-gang electrical box
(American type, not supplied)
[Front]
[Bottom]
[Front view without panel]
[Figure when mounted]
[Side] [Rear]
17.7. ZM-9013
Unit: mm (in)
