Toa A-9120DHM2 - Ss-9001

129
17.9. SS-9001
Unit: mm (in)
1
(0.04)
30 (1.18)
18
(0.71)
18
(0.71)
70 (2.76)
112 (4.41)
157 (6.18)
197 (7.76) 177 (6.97)10
(0.39)
9000 SERIES
SPEAKER SELECTOR
ZONE 1IN 1
70V/100V MAX. 240W
70V/100V MAX. 240W
IN
2
ZONE 2
ZONE 2
ZONE 1
G
G
G
G
ZONE 4
ZONE 3
ZONE 3
CTRL IN
DC IN
24V
120mA
IN 2
IN 2
ZONE 4
IN 2
IN 2
