Toa A-9120DHM2 - ZM-9011 Dimensions

126
38 (1.5)
42 (1.65)
6
(0.24)
49.5 (1.95)
40.5 (1.59)
70 (2.76)
72 (2.83)
33 (1.3)
66.4 (2.61)
97 (3.82)
127 (5)
[Front]
[Bottom] [Figure when mounted] [Dimensions of mounting opening]
[Front View without panel]
[Side]
1-gang electrical box (not supplied)
32.6
(1.28)
66 (2.6)
83.5 (3.29)
97 (3.82)
104 (4.09)
83.5
(3.29)
90 – 98
(3.54 – 3.86)
46 – 50 (1.81 – 1.97)
6
(0.24)
57.5 (2.26)
40.5 (1.59)
70 (2.76)
[Front]
[Bottom] [Figure when mounted] [Dimensions of mounting opening]
[Front View without panel]
[Side]
1-gang electrical box (not supplied)
72 (2.83)
33 (1.3)
66.4 (2.61)
97 (3.82)
127 (5)
38 (1.5)
42 (1.65)
32.6
(1.28)
66 (2.6)
83.5 (3.29)
97 (3.82)
104 (4.09)
83.5
(3.29)
90 – 98
(3.54 – 3.86)
46 – 50 (1.81 – 1.97)
17.5. ZM-9011
Unit: mm (in)
17.6. ZM-9012
Unit: mm (in)
