Toa A-9120DHM2 - Zm-9014; Ss-9001

159
26.6.9. SS-9001
Supplied from the optional AD-246 AC adapter or
an external 24 V DC/200 mA power supply.
120 mA
No-voltage make contact input (polarized), open voltage: 24 V DC,
short-circuit current: 3 mA
Under 240 W (70 V/100 V line)
Removable terminal block (2 pins)
Removable terminal block (10 pins)
–10 to +40°C (32 – 104°F)
Case: Surface-treated steel plate
112 (w) x 197 (h) x 30 (d) mm (4.41" x 7.76" x 1.18")
530 g (1.17 lb)
Power Source
Current Consumption
Control Signal
Control Power
Speaker Terminal
Control Terminal
Operating Temperature
Finish
Dimensions
Weight
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Removable terminal plug (2 pins) .................... 6
Removable terminal plug (10 pins) .................. 1
Cord clamp ....................................................... 1
Tapping screw 4 x 20 ....................................... 4
26.6.8. ZM-9014
24 V DC (supplied from RC-001T)
40 mA or less
Removable terminal block (10 pins)
Shielded CPEV cable (paired data line and paired power line) or
Category 5 twisted pair cable for LAN (CAT5-STP)
0 to +40°C (32 – 104°F)
35% to 80%RH (no condensation)
4 function buttons
1 volume control
4 function indicators (green LEDs)
Level indicators (green LEDs)
Surface-treated steel panel, white, paint
120 (w) x 127 (h) x 58.5 (d) mm (4.72" x 5" x 2.3")
300 g (0.66 lb)
Power Source
Current Consumption
Terminal
Connection Cable
Operating Temperature
Operating Humidity
Operating Section
Indicator
Finish
Dimensions
Weight
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Box mounting screw (No. 6-32UNC x 30) ........ 4
Box mounting screw (M4 x 30) ........................ 4
Panel mounting screw ...................................... 4
Removable terminal plug (10 pins) .................. 1
