In such setting on the previous page, the remote controller with address "0" functions as a remote controller
that can switch Input 1, 2, or 3 for Output 1.
Similarly, the remote controller with address "1" functions a remote controller that can switch Input 1, 2, or 3
for Output 2.
BGM 2 player
BGM 1 player
BGM 3 player
Input channel 1
Input channel 2
Input channel 3
Zone 1 (Output channel 1)
Remote controller
with address "0"
BGM 1 BGM 3
Zone 2 (Output channel 2)
9000M2 series
Remote controller
with address "1"
BGM 1
BGM 2
BGM 3
BGM 1
BGM 2
BGM 3
In the system above, the BGM sound source to be broadcast to Zone 1 can be selected with the buttons on
the remote controller with address "0."
Similarly, the BGM sound source to be broadcast to Zone 2 can be selected with the buttons on the remote
controller with address "1."
Notes
• When a scene memory is recalled while the cross point ON/OFF function is performed by the remote
controller, the system operation is brought into the state set in the scene memory. (Scene memory takes
precedence.)
• Paging input channel’s cross point cannot be turned ON or OFF by the remote controller.
