57
(A5) Phantom power ON/OFF setting
(when the D-001T/R is used)
I N 1 - P H A N T O M O F F
(A7) BASS and TREBLE settings (when the D-001T/R is used)
B A S S 0 T R E B L E 0
(A8) Loudness compensation setting (when the D-001T/R is used)
L O U D N E S S - O F F
(A6) NOM attenuation ON/OFF setting (when the D-001T/R is used)
I N 1 - N O M - O FF
Set the Phantom power to ON or OFF.
Notes
• When the module is the D-001R, this function can be set to ON but cannot be output.
• The Phantom power cannot be set to ON for the stereo-linked input channel.
• ON: Supplies the phantom power. (except D-001R)
• OFF: Does not supply the phantom power.
ON, OFF (default)
Setting Range
Set the NOM attenuation function (p. 40 "Glossary") to ON or OFF.
This function relates to the Gate ON/OFF setting and Gate threshold setting that appear later.
The NOM attenuation cannot be set to ON for the stereo-linked input channel.
• ON: Activates the NOM attenuation function.
• OFF: The NOM attenuation function does not work.
ON, OFF (default)
Setting Range
Rotate the Parameter setting knob to set gains.
Press the Right or Left shift key to select BASS or TREBLE, of which gain value that flashes can be adjusted.
–12 dB to +12 dB (default: 0 dB), 1 dB steps
Setting Range
Rotate the Parameter setting knob to set the loudness compensation function ON/OFF.
Setting ON boosts low frequencies.
ON, OFF (default)
Setting Range
