(A15) Trigger setting
(for the channel on which the module
other than the ZP-001T is used)
(A15) Trigger setting
(for the channel on which the ZP-001T
is used)
P A G I N G T R I G C
-
I N
P A G I N G T R I G Z P
(When the D-001T/R is used and the gate function is ON)
(A16) Gate threshold level setting
G A T E
-
T H R E S H O L D
-
3 0
(A17) Paging trigger control input terminal setting
P A G I N G T R I G N O N E
Sets the control input terminal to be used for paging trigger.
(A18) Paging interlock setting
P A G I N G S Y N C O N
Sets whether or not to activate the control output synchronizing with paging initiation.
(A19) Paging-interlocked output terminal setting
S Y N C O U T C
-
O U T 0 1
Sets the control output terminal to be activated when the paging-interlocked output is set to ON in the above
item.
Set the trigger to initiate paging. Type of trigger differs depending on the module that uses the channel.
• VOX: Voice Operated Switch
Enables paging if the audio input signal exceeds a preset level. (When the D-001T or D-001R is used)
When Trigger is set to VOX, be sure to also set the Gate function for the paging input channel to ON.
• C-IN: Enables paging while the control input terminal is closed.
• ZP: Enables paging using the ZP-001T. (When the ZP-001T is used)
Modules except the ZP-001T, D-001T and D-001R: C-IN (default)
D-001T, D-001R: C-IN (default), VOX, ZM
ZP-001T: ZP (default)
Setting Range
Set the input sensitivity to activate the gate function (p. 40 "Glossary").
–40 to –5 dB (default: –30 dB), 5 dB steps
Setting Range
NONE, CIN01 - 12Setting Range
OFF (default), ONSetting Range
1 - 4 (12: when C-001T is used)Setting Range
