(C20) Monitor switching control input terminal setting (When the ANC monitor switching is set to ON)
M O N S E L E C T - > C - I N 0 1
Select the control input terminal to switch the ANC inputs* to be monitored.
Selecting the terminal overwrites the previously set function on it if there is.
Each time the designated terminal is closed, the ANC inputs to be monitored are switched in numerical order
from ANC input 1.
* ANC inputs are the input channels of AN-001T Ambient Noise Sensor Input module. One AN-001T module
has 2 input channels. When 2 AN-001T modules are mounted, the AN-001T's inputs in the slot with smaller
number correspond to ANC Input channels 1 and 2, and another's inputs in another slot to ANC Input
channels 3 and 4.
CIN01 – 04, CIN01 – 12 when C-001T is used (default: CIN01)
Setting Range
(C24) Lock status display
K E Y L O C K = U N L O C K E D
(C21) Interlock output control setting (When the ANC monitor switching is set to ON)
M O N S E L S Y N C = O N
(C23) Interlock output terminal setting
(When the ANC monitor switching is set to ON, and the interlock output control to ON)
A N 1 S Y N C - > C O U T 0 1
(C22) Monitored ANC input channel selection
(When the ANC monitor switching is set to ON, and the interlock output control to ON)
S E L E C T S Y N C - > A N 1
Perform ON/OFF setting for the function that closes the control output terminal in synchronization with the
control input terminal closure of the set number.
OFF (default), ON
Setting Range
Select the ANC input channel. Each channel for which the monitor function is set to ON can be selected.
ANC 1 – 4 (Only ANC input channels for which the monitor function is ON)
Setting Range
Set the control output terminal which is closed in synchronization with switching to the monitored ANC input
channel.
Assigning the function to this terminal overwrites the previously set function on it if there is.
COUT01 – 04, COUT01 – 12 when C-001T is used (default: COUT01)
Setting Range
The above screen displays the current key lock status.
When a key other than the Utility key is locked, "UNLOCKED" is indicated. If a locked key is pressed, the
display changes to the password entry screen. To enter the key lock setting flow, press the Enter key.
UNLOCKED (default), LOCKED
Setting Range
(C25) Key lock setting
K E Y L O C K S E T T I N G ?
Confirmation screen to enter the key lock setting.
Press the Enter key or Right Shift key to perform the key lock setting.
