87
(C68)
(When the control output function is set to CH ON)
C - O U T 0 1 - > C H O N
(C67) Scene memory bank number selection
C - O U T 0 1 - L D S C E N E 0 1
(C69) Input/Output channel number selection
C - O U T 0 1 - C H O N - > I N 1
(C66)
(When the control output function is set to SCENE)
C - O U T 0 1 - > L D S C E N E
[When the function is set to SCENE]
Provides a Level output when a Scene memory is recalled.
Assigning a function to this terminal overwrites the previously set function on it if there is.
Select the Scene memory bank number that causes the selected control output terminal to provide a Level
output when the Scene memory is recalled.
01 -32
(default: 01)
Setting Range
[When the function is set to CH ON]
Provides a Level output when the input or output channel becomes on.
Assigning a function to this terminal overwrites the previously set function on it if there is.
Select the input or output channel number that causes the selected control output terminal to provide a Level
output when the channel becomes on.
IN1 – 8, OUT1 – 2,
Max. OUT8 when T-001Ts are used
(default: IN1)
Setting Range
