FUEL SYSTEM
INSTALLATION
Connect the air flow tube [1] to the throttle body [2]
securely while pushing the main harness [3] down.
• Take care that the main harness is not damaged by
the air flow clamp [4].
Install and tighten the two bolt/washers (6 x 25 mm) [2]
and two bolts (6 x 60 mm) [3].
Tighten the air flow clamp screw [1] securely.
Connect the crankcase breather hose [2] to the cooling
fan cover [3] and set it to the grommet clamp [4].
[2]
[1]
[4]
[3]
[2]
[1]
[1]
[3]
[2]
[4]
